PARTICULATE MATTER, TEMPERATURE, HUMIDITY AND BAROMETRIC PRESSURE SENSOR FOR LoRaWAN®
APPLICATIONS
General indoor and outdoor air quality monitoring
Global environmental surveillance
Indoor air quality monitoring in offices, class rooms, hospitals, stores or malls
Heating, ventilation and air conditioning (HVAC) control:
for good indoor air quality and energy savings
SENSORS
MASS CONCENTRATION
PM1, PM2.5
Range: 0 … 100 μg/m3
Accuracy: ±[5 μg/m3 + 5 %]
Range: 100 … 1000 μg/m3
Accuracy: ±10 %
PM4, PM10
Range: 0 … 100 μg/m3
Accuracy: ±25 μg/m3
Range: 100 … 1000 μg/m3
Accuracy: ±25 %
TEMPERATURE
Range: -40 ... + 125 °C
Accuracy: ±0.3 °C
RELATIVE HUMIDITY
Range: 0 ... 100% RH
Accuracy: ±2% RH
BAROMETRIC PRESSURE
Range: 300 ... 1'100 hPa
Accuracy: ±1 hPa absolute, ±0.12 hPa relative
DEVICE
LoRaWAN® class A
External power supply: 5.0 VDC regulated, 0.1 A max.
12.2 cm x 8.1 cm x 6.7 cm
Reference DL-PM
